Overview
This document gives a description of the RESTful web services exposed on the Creditswitch
Platform which enables business partners sell different products and track their account.
Our RESTful web service mainly uses data in JSON format for both input and output operations.
Http request header should be set to application/json or the corresponding data type.
For technical
assistance with the CSW API contact us at support@creditswitch.com.
The subject line should be CSW API:(ISSUE SNIPPET) to enable swift response and support.
Integration flow
This section contains a description of recommended integration flow which helps minimize the risk of disputing transactions and also increase customer confidence in the system.
Step One
If the service has a method for validating the customer, that method should be used first in order to make sure the customer is properly identified on provider platform and that products customer wishes to purchase are available at the moment.
Step Two
In case step 1 is successfully completed, a Vend request can be sent. If the HTTP status of the response is OK, then you can check the request status through status field which can be Successful or not. In either case, the request has been processed
Step Three
Possible alternative scenarios to an ideal step 2 include a Response timeout or a Connection error or any other error defined in our response
- In case of an error, you can safely resend the vend request – however, the request id must be updated.
- If a response with HTTP status OK is received, you can consider vend to have been carried out.
Step Four
In case the request returns with an error response multiple times, the client needs to contact Creditswitch support in order to resolve the issue.
Get Merchant Info
Get Allowed Services operation enables Creditswitch integrator to fetch current info about integrator’s account, such as the balance, allowed ip addresses, available services, and the discount given for each service.
| Service | Merchant Info |
|---|---|
| Request URL | baseUrl/api/v1/mdetails |
| HTTP Method | POST |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId":1234, "key":"0688378ec7fe233","checksum":"#2y*&23UnvC19"}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | Collection | M | An array of merchant details |
"statusDescription" Body:
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| name | Numeric | M | Merchant’s name supplied during production endpoint setup |
| balance | String | M | Merchant’s name supplied during production endpoint setup |
| status | String | M | Status of the Merchant’s account |
| String | M | Email of the merchant | |
| allowedIps | Collection | M | Array of Ip’s configured for merchant |
| serviceDetail | Collection | M | A multidimensional array of (service ids and the corresponding commissions) for each |
| transactionsToday | String | M | Total daily transaction count for merchant |
Sample Response Body
{"statusCode":"00",
"statusDescription":
{"name":" Test Test ","balance":"2855.00","status":"active","email":"support@test.com ",
"allowed_ips":["127.0.0.1"],"serviceDetail":[["A01E","5.00"],["A02E","5.00"],
["A03E","5.00" ],["A04E","5.00"],["D01D","0.00"],["D02D","0.00"],
["D03D","0.00"],["D04D","0.00"]],"transac tionsToday":0}
}
Requery
Requery is used to check the status of an existing transaction.
| Service | Requery |
|---|---|
| Request URL | baseUrl/api/v1/requery |
| HTTP Method | GET (QUERY STRING) |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Requery id provided during integration |
| key | String | M | Requery (public) key |
| requestId | String | M | Unique requery Id for the request. Maxlength (36characters) |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
Sample Request Body
"BASEURL/api/v1/requery?loginId=17899&serviceId=A01E&key=f7a2b427ded4825675b306741ff27a9243b938faa7fb2db2a5615fd&requestId=17425905"
Response Body for Airtime and Data
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | Collection | M | An array of merchant details |
| mReference | String | M | Unique transaction id supplied by the merchant for the request |
| tranxReference | Numeric | M | Creditswitch’s unique id generated for the transaction |
| recipient | String | M | Customer's phone number/ smartcard number/ meter number |
| amount | Numeric | M | Amount |
| confirmCode | Numeric | M | Confirmation code returned by the network. Sent only for successful transactions |
| network | String | M | The actual network fulfilled by the Telco |
| tranxDate | Numeric | M | Date at which transaction was carried out |
Sample Response Body
{"statusCode": "00","statusDescription": "Successful", "mReference": "12345","tranxReference": 255951583852071,
"recipient": "01234567891","amount": "900.00","network": "MTN","tranxDate": "2020-03-10 15:54:31"
}
Response Body for Electricity
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | Collection | M | An array of merchant details |
| mReference | String | M | Unique transaction id supplied by the merchant for the request |
| tranxReference | Numeric | M | Creditswitch’s unique id generated for the transaction |
| recipient | String | M | Customer's phone number/ smartcard number/ meter number |
| amount | Numeric | M | Amount |
| token | Numeric | O | Transaction token returned only for electricity |
| tranxDate | Numeric | M | Date at which transaction was carried out |
Sample Response Body
{"statusCode": "00","statusDescription": "Successful", "mReference": "12345","tranxReference": 255951583852071,
"recipient": "01234567891","amount": "900.00","token": "01008669212634221201","tranxDate": "2020-03-10 15:54:31"
}
Airtime Vend Request
Service to perform airtime top-up of customer’s phone number through merchant’s account
| Service | Merchant Info |
|---|---|
| Request URL | baseUrl/api/v1/mvend |
| HTTP Method | POST |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| requestId | String | M | Unique transaction Id for the request. Maxlength (36characters) |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| amount | Numeric | M | Amount with which to top-up amount customers phone Maximum 100000 |
| recipient | Numeric | M | Customers phone number to top-up |
| date | String | M | Date-time at which the request was sent . |
| checksum | Numeric | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId": 1234,
"key":"0688378ec7fe233","requestId":"11345","serviceId":"A01E", "amount":"100", "recipient":"08030001111",
"date":"2-Jul-2017 18:30 GMT","checksum":"#2y*&23UnvC19" }
Sample JAMB Request Body
{"loginId": 1434,
"key":"0688378ec7fe233","requestId":"11345","serviceId":"A01E", "amount":"4000", "recipient":"08030001111",
"date":"2-Jul-2017 18:30 GMT","checksum":"#2y*&23UnvC19" , "confirm code":"kvrbv3fjrv", "email":"support@creditswitch.com", "jambType":"jambutme"}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| mReference | String | M | Unique transaction id supplied by the integrator for the request |
| tranxReference | Numeric | M | Creditswitch’s unique id generated for the transaction |
| recipient | String | M | Customers number on the network to which top-up was sent |
| amount | Numeric | M | Amount credited the customer |
| confirmCode | Numeric | M | Confirmation code returned by the network. Sent only for successful transactions |
| Network | String | M | The actual network fulfilled by the Telco |
| tranxDate | Numeric | M | Date at which transaction was carried out |
Sample Response Body
{"statusCode":"00","statusDescription":"Successful","mReference":"11345",
"tranxReference":" 123452114", "recipient":"08030001111", "amount":"100",
"confirmCode":"R20170707.2150.234565","network":"MTN",tranxDate":"21-06-2017 10:25 am"}}
Data Plans
This service provides all available and active data plans based on the serviceId provided.
| Service | DATA PLANS RETRIEVAL |
|---|---|
| Request URL | baseUrl/api/v1/mdataplans |
| HTTP Method | POST |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| key | String | M | Merchants (public) key |
Sample Request Body
{"loginId":1234,"serviceId":"D02D","key":"0688378ec7fe233" }
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| serviceId | String | M | The serviceId provided in the request body |
| productId | String | M | The corresponding productId |
| dataPlan | String | M | An array of all data plans available for the supplied serviceId |
Sample Response Body
{"statusCode": "00","statusDescription": "successful","serviceId": "D02D","dataPlan": [
{"amount": 50,"databundle": "25MB","validity": "1day","productId": "9MO-25MB-15"},{"amount": 100,"databundle": "100MB","validity": "1day","productId": "9MO-100MB-1"},
{"amount": 200,"databundle": "650MB","validity": "1day","productId": "9MO-650MB-2"},{"amount":1000,"data bundle":"1GB","validity":"30days,"productId": "9MO-1GB-3"},
{"amount":1200,"databundle":"1.5GB","validity":"30days,productId": "9MO-1.5GB-4"},{"amount": 1500,"databundle": "7GB","validity": "7days","productId": "9MO-7GB-16"},
{"amount":2000,"databundle":"4.5GB","validity":"30days,"productId": "9MO-4.5GB-5"},{"amount":3000,"databundle":" 4GB","validity":"30days,"productId": "9MO-4GB-6"},
{"amount":4000,"databundle":"5.5GB","validity":"30days,"productId": "9MO-5.5GB-7"},{"amount":8000,"databundle":"11.5GB","validity":"30days,"productId": "9MO-11.5GB-8"},
{"amount":10000,"databundle":"15GB", "validity":"30days,"productId": "9MO-15GB-9"},{"amount":18000,"databundle":"27.5GB","validity":"30days,"productId": "9MO-27.5GB-10"},
{"amount": 27500,"databundle":"30GB","validity":"90days,"productId": "9MO-30GB-11"},{"amount":55000,"databundle":"60GB","vali dity":"180days,productId": "9MO-60GB-12"},
{"amount":84992,"databundle":"100GB","validity":"100days,"productId": "9MO-100GB-13"},{"amount":11 0000,"databundle":"120GB","validity":"365days,"productId": "9MO-120GB-14"}]}
Data Vend Request
Service to perform data top-up of customer’s phone number through merchant merchant’s account
| Service | Merchant Info |
|---|---|
| Request URL | baseUrl/api/v1/dvend |
| HTTP Method | POST |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchant’s (public) key supplied during integration |
| requestId | String | M | Unique transaction Id for the request. Maxlength (36characters) |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| amount | Numeric | M | Amount with which to top-up amount customers phone Maximum 100000 |
| recipient | Numeric | M | Customers phone number to top-up |
| date | String | M | Date-time at which the request was sent . |
| productId | String | M | the identifier of each data bundle e.g MTN-25MB-10. |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId": "1234","key": "f7a2b427dedbdbdc4825675","requestId": "abcde1234","serviceId": "D04D",
"recipient": "080xxxxxxxx","amount": "50.00","productId": "MTN-25MB-10","date": "13-11-2019T09:28:38.273+01:00",
"checksum": "JDJ5JDEwJGRQZ0Y4UWZkUnFNNFQzaXpnOWsuOWVWTkVVRS9QNC85OU9IR2lVYVNwTUYyY05NLlB1Qjd1" }
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| mReference | String | M | Unique transaction id supplied by the integrator for the request |
| tranxReference | Numeric | M | Creditswitch’s unique id generated for the transaction |
| recipient | String | M | Customers number on the network to which top-up was sent |
| amount | Numeric | M | Amount credited the customer |
| confirmCode | Numeric | M | Confirmation code returned by the network. Sent only for successful transactions |
| network | String | M | The actual network fulfilled by the Telco |
| tranxDate | Numeric | M | Date at which transaction was carried out |
Sample Response Body
{"statusCode": "00","statusDescription": "Successful","mReference": "abcde1234","tranxReference": "12345678",
"recipient": "080xxxxxx","amount": "50.00","confirmCode": "1234567890","network": "MTN",
"tranxDate": "17-01-2020 12:01 pm"}}
International Services
List International Countries
This Lists all the countries supported for international bill payments.
| Service | |
|---|---|
| Request URL | baseUrl/intl_services/get_countries?key={{publicKey}}&loginId={{loginId}} |
| HTTP Method | GET |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| data | String | M | Contains the dataset of countries supported |
Sample Response Body
{
'statusCode': '00',
'statusDescription': 'successful',
'data': {
'USD': {
'country': 'United State Of America',
'currency': 'USD',
'currency_code': '840'
},
'GBP': {
'country': 'United Kingdom',
'currency': 'GBP',
'currency_code': '826'
},
'CAD': {
'country': 'Canada',
'currency': 'CAD',
'currency_code': '124'
}
}
}
List International Services for Country
This Lists all the services supported for international bill payments by a country.
| Service | |
|---|---|
| Request URL | baseUrl/intl_services/get_services?key={{publicKey}}&loginId={{loginId}}& currency={{usd}} |
| HTTP Method | GET |
| Request Headers | application/json |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| data | String | M | Contains the dataset of services supported by a particular country |
Sample Response Body
{
'statusCode': '00',
'statusDescription': 'successful',
'data': [
{
'service_code': 'INT1',
'service_name': 'AT&T-Mobile Top Up',
'currency': 'USD',
'provider_min_amount': '15',
'provider_max_amount': '100',
'hasPackages': 0,
'packages': []
},
{
'service_code': 'INT2',
'service_name': 'T-Mobile-Mobile Top Up',
'currency': 'USD',
'provider_min_amount': '10',
'provider_max_amount': '100',
'hasPackages': 0,
'packages': []
},
{
'service_code': 'INT3',
'service_name': 'Verizon Wireless-Mobile Top Up',
'currency': 'USD',
'provider_min_amount': '15',
'provider_max_amount': '100',
'hasPackages': 0,
'packages': []
}
]
}
Get Exchange Rate
Get exchange rate for a particular currency.
| Service | |
|---|---|
| Request URL | baseUrl/intl_services/exchange_rate?key={{publicKey}}&loginId={{loginId}}& currency=usd&amount=2 |
| HTTP Method | GET |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| currency | String | M | The currency you are converting to. it must be part of the countries from the get countries API call. |
| amount | Numeric | M | The currency amount you want to convert. |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| data | String | M | Contains the dataset of the conversion |
Sample Response Body
{
'statusCode': '00',
'statusDescription': 'successful',
'data': {
'currency_name': 'USD',
'currency_rate': 2980
}
}
Vend International Service
Make Payment for International service.
| Service | |
|---|---|
| Request URL | baseUrl/intl_services/vend |
| HTTP Method | POST |
| Request Headers | application/json |
Sample Request Body
{
'loginId': '{{loginId}}',
'key': '{{publicKey}}',
'serviceId': 'INT5',
'amount': '10',
'requestId': '{{randomsomethingdigit}}',
'recipient': '447760929652'
}
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| requestId | Numeric | M | unique id to identify transaction |
| key | String | M | Merchants (public) key |
| serviceId | String | M | The serviceId of the plan. it must be part of the services from the get services API call. |
| amount | Numeric | M | The currency amount of the service. |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| detail | String | M | Contains the details of the payment |
| detail.extraDetails | Array | M | This can be empty, if a direct top up is done this value would be empty, if a pin recharge is done values would be returned. |
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Successful",
"detail": {
"tranxReference": "3240606165442171768",
"mReference": "27aa2545a0650287",
"recipient": "447760928328",
"amount": "10",
"converted_currency_value": 19485,
"network": "ASDA Mobile-Mobile Top Up",
"extraDetails": {
"confirmCode": "80801846182",
"pin": "51705318689061",
"serial": "127472436827",
"message": "To redeem code There are 3 ways to activate your ASDA Mobile-Mobile Top Up code: Online: 1. Go to your My3 account. 2. Log in with your mobile number, Broadband number, or Username and Password. 3. Follow the instructions on the page and enter your 14-digit top up code. Calling:\n\n Call 7823 from the phone you wish to top up.\n When asked by the operator, enter your 14-digit top up code.\n Texting:\n Open a new text message to 75712.\n In the message, type top up + your 14-digit top up code."
}
}
}
Send SMS
Service to send single and bulk SMS
Single SMS
Send SMS to a single recipient
| Service | Merchant Info |
|---|---|
| Request URL | baseUrl/api/v1/sendsms |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| senderId | String | M | Sender Id for the send SMS request. |
| msisdn | String | M | Recipient / phone number. Ex: 09062120000 |
| amount | Numeric | M | Amount with which to top-up amount customers phone Maximum 100000 |
| messageBody | Text | M | Message body for send SMS request |
| transactionRef | String | M | Unique transaction Id for the request. Maxlength (35characters) |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId":"1234","key":"f7a2b42…", "senderId":"TEST-NG",
"msisdn":"09062120000", "messageBody":"Keep calm and test", "transactionRef":"008k97658891", "checksum":"JDhJk…"}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| cost | Numeric | M | Cost of sent SMS (in naira) |
| tranxReference | Numeric | M | Merchant/client’s initial transaction reference |
| transactionId | Numeric | M | Creditswitch’s unique id generated for the transaction |
Sample Response Body
{"statusCode":"00","statusDescription":"successful","cost":2.5,
"transactionRef":"pp0p88097976 58891","transactionId":"167241535005733"}
Bulk SMS
Send SMS to a bulk recipients
| Service | Merchant Info |
|---|---|
| Request URL | baseUrl/api/v1/sendsms |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| senderId | String | M | Sender Id for the send SMS request. |
| msisdn | String | M | An array of Recipient / phone number. Ex: 09062120000 |
| amount | Numeric | M | Amount with which to top-up amount customers phone Maximum 100000 |
| messageBody | Text | M | Message body for send SMS request |
| transactionRef | String | M | Unique transaction Id for the request. Maxlength (35characters) |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId":"60789","key":"$2y$10$J39dLRgZ5vsIhu0030YVjuaSMirHalM8b0JBIpG0Jt9RCcOH1KEEu","senderId":"Creditswtch",
"msisdn":[09034575188","08123748177"], "messageBody":"Testing", "transactionRef":"12ddsa73sde2hsdkklo7", "checksum":"JDJ5JDEwJGNZVHUuQ2l4SkVsV0VsaTVwSi9GYnUubEM4eFdOcHR0SERRLmJ2ZFdxQko0STloNC5hSEJ1"}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| cost | Numeric | M | Cost of sent SMS (in naira) |
| tranxReference | Numeric | M | Merchant/client’s initial transaction reference |
| transactionId | Numeric | M | Creditswitch’s unique id generated for the transaction |
Sample Response Body
{"statusCode":"00","statusDescription":"successful","cost":2.5,
"transactionRef":"pp0p88097976 58891","transactionId":"167241535005733"}
Insurance
Service to Pay for Insurance This web service is in two phases: (1) get product codes (2) vend – can take place.
1) Insurance GET PACKAGES
| Service | Insurance Packages |
|---|---|
| Request URL | {{baseUrl}}insurance/packages |
| HTTP Method | GET |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}"
} NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": {
"items": {
"insuranceName": [
"LAW UNION & ROCK INSURANCE"
],
"insuranceType": [
{
"name": "TRICYCLE",
"amount": "2500"
},
{
"name": "PRIVATE_MOTOR",
"amount": "5000"
},
{
"name": "COMMERCIAL",
"amount": "7500"
}
],
"vehicleColor": [
"ASH",
"BRONZE",
"BEIGE",
"BLACK",
"BLUE",
"BROWN",
"CREAM",
"CUSTOM",
"GOLD",
"GREEN",
"GREY",
"NAVY BLUE",
"ORANGE",
"PEACH",
"PINK",
"PURPLE",
"RED",
"SILVER",
"VIOLET",
"WHITE",
"WIINE",
"YELLOW"
],
"yearOfMake": [
"1990",
"1991",
"1992",
"1993",
"1994",
"1995",
"1996",
"1997",
"1998",
"1999",
"2000",
"2001",
"2002",
"2003",
"2004",
"2005",
"2006",
"2007",
"2008",
"2009",
"2010",
"2011",
"2012",
"2013",
"2014",
"2015",
"2016",
"2017",
"2018",
"2019",
"2020"
]
}
}
}
2) INSURANCE RECHARGE
| Service | Insurance Account vend |
|---|---|
| Request URL | {{baseUrl}}insurance/pay |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| requestId | Numeric | M | Unique transaction Id for the request. Maxlength (36characters) |
| ServiceId | String | M | INS0 |
| Insured Name | String | M | Customer Name. |
| Insurance Type | String | M | Insurance Type gotten from the get Insurance package API Call |
| chassis_number | Numeric | M | Chassis Number of the vehicle to be Insured |
| engine_number | String | M | Engine Number of the vehicle to be Insured |
| plate_number | String | M | Plate Number of the vehicle to be Insured |
| vehicle_make | String | M | Make of the vehicle to be Insured, e.g Toyota, Ford |
| vehicle_model | Numeric | M | Model of the vehicle to be Insured, e.g Camry, Matrix |
| vehicle_color | String | M | Color of the vehicle to be Insured, e.g Blue, Black |
| year_of_make | Numeric | M | Year of the vehicle to be Insured, e.g Blue, Black |
| String | M | Email of the Customer | |
| contact_address | Numeric | M | Contact Address of the customer |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"requestId": "{{random12digit}}",
"serviceId": "INS0",
"insured_name": "David OG",
"insurance_type": "PRIVATE_MOTOR",
"chassis_number": "7338388393951",
"engine_number": "1234rtrg5g5g",
"plate_number": "AS53333Rfr5",
"customerId": "08047621639",
"amount": "5000",
"vehicle_make": "TOYOTA",
"vehicle_model": "CAMRY",
"vehicle_color": "BLACK",
"year_of_make": "2010",
"email": "test123@gmail.com",
"contact_address": "dkij"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Successful",
"status": true,
"result": {
"amount": "100.00",
"message": "transaction Successful",
"transId": "929281645462237",
"date": "2022-02-21 16:50:40",
"package": "Showmax Mobile",
"subscriptionPeriod": "1",
"subscriptionType": "mobile_only",
"validUntil": "2025-02-21 16:50:39 UTC",
"voucherCode": "788623",
"captureUrl": "https://secure.showmax.io/payment/subscriptions/access_code"
}
}
Showmax
Service to recharge Showmax This web service is in two phases: (1) get product codes (2) vend – can take place.
1) SHOWMAX GET PACKAGES
| Service | Showmax Packages |
|---|---|
| Request URL | {{baseUrl}}showmax/packages |
| HTTP Method | GET |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}"
} NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": {
"items": [
{
"name": "Showmax Mobile",
"subscriptionPeriod": 1,
"price": 1200,
"type": "mobile_only"
},
{
"name": "Showmax Mobile",
"subscriptionPeriod": 3,
"price": 2499,
"type": "mobile_only"
},
{
"name": "Showmax Mobile",
"subscriptionPeriod": 6,
"price": 4299,
"type": "mobile_only"
},
{
"name": "Showmax Mobile",
"subscriptionPeriod": 12,
"price": 7200,
"type": "mobile_only"
},
{
"name": "Showmax",
"subscriptionPeriod": 1,
"price": 1200,
"type": "full"
},
{
"name": "Showmax",
"subscriptionPeriod": 3,
"price": 5999,
"type": "full"
},
{
"name": "Showmax",
"subscriptionPeriod": 6,
"price": 10400,
"type": "full"
},
{
"name": "Showmax",
"subscriptionPeriod": 12,
"price": 17400,
"type": "full"
},
{
"name": "Showmax Pro Mobile",
"subscriptionPeriod": 1,
"price": 3200,
"type": "sports_mobile_only"
},
{
"name": "Showmax Pro Mobile",
"subscriptionPeriod": 3,
"price": 9600,
"type": "sports_mobile_only"
},
{
"name": "Showmax Pro Mobile",
"subscriptionPeriod": 6,
"price": 19200,
"type": "sports_mobile_only"
},
{
"name": "Showmax Pro Mobile",
"subscriptionPeriod": 12,
"price": 38400,
"type": "sports_mobile_only"
},
{
"name": "Showmax Pro",
"subscriptionPeriod": 1,
"price": 6300,
"type": "sports_full"
},
{
"name": "Showmax Pro",
"subscriptionPeriod": 3,
"price": 18900,
"type": "sports_full"
},
{
"name": "Showmax Pro",
"subscriptionPeriod": 6,
"price": 37800,
"type": "sports_full"
},
{
"name": "Showmax Pro",
"subscriptionPeriod": 12,
"price": 75600,
"type": "sports_full"
}
]
}
}
2) SHOWMAX RECHARGE
| Service | Showmax Account vend |
|---|---|
| Request URL | {{baseUrl}}showmax/pay |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| ServiceId | String | M | SOMX |
| customerNo | String | M | Phone Number. |
| Amount | Numeric | M | Amount of the package gotten from the get SHOWMAX package API Call |
| requestId | Numeric | M | Unique transaction Id for the request. Maxlength (36characters) |
| subscriptionType | Numeric | M | Type of Subscription, gotten from the get Packages API call |
| invoicePeriod | Numeric | M | This is the value of subscriptionPeriod gotten from the get SHOWMAX package API call |
| packageName | Numeric | M | Name of package gotten from the get SHOWMAX package API call |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"serviceId" : "SOMX",
"customerNo":"09058639550",
"amount": 100,
"requestId" : "{{random12digit}}",
"subscriptionType" : "mobile_only",
"invoicePeriod" : "1",
"packageName" : "Showmax Mobile"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Successful",
"status": true,
"result": {
"amount": "100.00",
"message": "transaction Successful",
"transId": "929281645462237",
"date": "2022-02-21 16:50:40",
"package": "Showmax Mobile",
"subscriptionPeriod": "1",
"subscriptionType": "mobile_only",
"validUntil": "2025-02-21 16:50:39 UTC",
"voucherCode": "788623",
"captureUrl": "https://secure.showmax.io/payment/subscriptions/access_code"
}
}
NOTE: voucherCode is what the customer would need to activate subscription
Cable TV Startimes
Service to recharge Startimes cable TV account. This web service is in two phases: (1) validate – an endpoint to validate smart card code must be queried before (2) vend – can take place.
1) STARTIMES FETCH PRODUCTS
| Service | Fetch Startimes Product |
|---|---|
| Request URL | baseUrl/api/v1/startimes/fetchProductList |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
Sample Request Body
{
"loginId":"1234",
"key":"f7a2b..."
}NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": {
"items": [
{
"availablePricingOptions": [
{
"price": "90",
"invoicePeriod": ""
}
],
"code": "DTT_Nova_Daily",
"name": "DTT_Nova_Daily"
},
{
"availablePricingOptions": [
{
"price": "160",
"invoicePeriod": ""
}
],
"code": "DTT_Basic_Daily",
"name": "DTT_Basic_Daily"
},
]
}
}1) SMARTCARD CODE VALIDATION
| Service | Startimes Account validate |
|---|---|
| Request URL | baseUrl/api/v1/starvalidate1 |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
| smartCardCode | String | M | Smart card code. |
Sample Request Body
{"loginId":"1234","key":"f7a2b...","checksum":"JDJhJDEw…","smartCardCode":"920000028 66"}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{"statusCode": "00", "statusDescription": "successful", "balance": 2644,
"customerName": "Mr Tester CSW", "smartCardCode": "92000002866" }
2) SMARTCARD RECHARGE
| Service | Startimes Account vend |
|---|---|
| Request URL | baseUrl/api/v1/starvend1 |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
| smartCardCode | String | M | Smart card code. |
| fee | Numeric | M | Amount to recharge smart card |
| transactionRef | Numeric | M | Unique transaction Id for the request. Maxlength (36characters) |
Sample Request Body
{"loginId":"1234","key":"f7a2b4….","checksum":"JDJhJDEw…",
"smartCardCode":"9200000 2866", "fee":"400","transactionRef":"232pxz"}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{"statusCode": "00", "statusDescription": "successful",
"details": "succeeded, smart card empty,mobile phone empty,amount NGN 1.00,balance empty,transaction id 940020180823085017270261,product name empty,product description empty .",
"transactionNo": "940020180823085017270261"}
Cable TV: Multichoice(DSTV & GOTV)
Service to pay for an existing subscription on Multichoice (DSTV and GOTV) cable TV account. Basically, there are three (3) phases for this web service – validation of smart card number, fetching available multichoice product codes and account vending.
1) VALIDATE CUSTOMER NUMBER/SMARTCARD NUMBER
| Service | Validate Multichoice SmartCard/Customer Number |
|---|---|
| Request URL | baseUrl//api/v1/cabletv/multichoice/validate |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
| customerNo | String | M | Smart card number or Customer Number. |
| serviceId | String | M | Multichoice service type – ‘dstv’ or ‘gotv’. |
Sample Request Body
{"loginId":"1234","key":"f7a2b427de…","checksum":"JDJhJDE…","customerNo":"10553886499","serviceId":"dstv"}
Response Body:
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | json | M | Corresponding details retrieved after validating customer number or smartcard number. It holds information such as customer name, invoice period, next due date etc. |
Sample Response Body
{
"statusCode": "00",
"statusDescription": {
"customerNo": 300846162,
"firstname": "AYOBAMI OJO",
"lastname": "",
"customerType": "GOTV",
"invoicePeriod": "",
"dueDate": "2021-10-26T13:32:11.227+01:00",
"amount": 2500
}
}
2) FETCH MULTICHOICE PRODUCT CODES
This can be used to retrieve available multichoice products. Each product has a code, description and price. Product codes can be fetched by either of these two methods – finding available standalone products or finding available add-ons for a selected product.
a). Find Standalone Products
| Service | Find Standalone Products |
|---|---|
| Request URL | baseUrl//api/v1/cabletv/multichoice/fetchproducts |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| serviceId | String | M | Multichoice service type – ‘dstv’ or ‘gotv’. |
Sample Request Body
{"loginId":"1234","key":"f7a2b427d..","serviceId":"dstv"}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | json | M | statusDescription is a json that has embedded in it an ‘items’ object, which contains available products. items an array of composite objects – code, invoicePeriods, price, name, description |
Sample Response Body
{"statusCode":"00","statusDescription":{"items":[{"availablePricingOptions":[{"monthsPaidFor":1,"price":2000,"invoicePeriod":1},
{"monthsPaidFor":2,"price":4000,"invoicePeriod":1},{"monthsPaidFor":3,"price":6000,"invoicePeriod":1},{"monthsPaidFor":4,"price":8000,"invoicePeriod":1},{"monthsPaidFor":5,"price":10000,"invoicePeriod":1},
{"monthsPaidFor":6,"price":12000,"invoicePeriod":1},{"monthsPaidFor":7,"price":14000,"invoicePeriod":1},{"monthsPaidFor":8,"price":16000,"invoicePeriod":1},{"monthsPaidFor":9,"price":18000,"invoicePeriod":1},
{"monthsPaidFor":10,"price":20000,"invoicePeriod":1},{"monthsPaidFor":12,"price":22000,"invoicePeriod":12}],"code":"ACSSE36","name":"DStv Access","description":" "},{"availablePricingOptions":[{"monthsPaidFor":1,"price":4000,"invoicePeriod":1},
{"monthsPaidFor":2,"price":8000,"invoicePeriod":1},{"monthsPaidFor":3,"price":12000,"invoicePeriod":1},{"monthsPaidFor":4,"price":16000,"invoicePeriod":1},{"monthsPaidFor":5,"price":20000,"invoicePeriod":1},
{"monthsPaidFor":6,"price":24000,"invoicePeriod":1},{"monthsPaidFor":7,"price":28000,"invoicePeriod":1},{"monthsPaidFor":8,"price":32000,"invoicePeriod":1},{"monthsPaidFor":9,"price":36000,"invoicePeriod":1},{"monthsPaidFor":10,"price":40000,"invoicePeriod":1},
{"monthsPaidFor":12,"price":44000,"invoicePeriod":12}],"code":"COFAME36","name":"DStv Family","description":" "},{"availablePricingOptions":[{"monthsPaidFor":1,"price":6800,"invoicePeriod":1},{"monthsPaidFor":2,"price":13600,"invoicePeriod":1},
{"monthsPaidFor":3,"price":20400,"invoicePeriod":1},{"monthsPaidFor":4,"price":27200,"invoicePeriod":1},{"monthsPaidFor":5,"price":34000,"invoicePeriod":1},{"monthsPaidFor":6,"price":40800,"invoicePeriod":1},{"monthsPaidFor":7,"price":47600,"invoicePeriod":1},
{"monthsPaidFor":8,"price":54400,"invoicePeriod":1},{"monthsPaidFor":9,"price":61200,"invoicePeriod":1},{"monthsPaidFor":10,"price":68000,"invoicePeriod":1},{"monthsPaidFor":12,"price":74800,"invoicePeriod":12}],"code":"COMPE36","name":"DStv Compact","description":" "},
{"availablePricingOptions":[{"monthsPaidFor":1,"price":10650,"invoicePeriod":1},{"monthsPaidFor":2,"price":21300,"invoicePeriod":1},{"monthsPaidFor":3,"price":31950,"invoicePeriod":1},{"monthsPaidFor":4,"price":42600,"invoicePeriod":1},
{"monthsPaidFor":5,"price":53250,"invoicePeriod":1},{"monthsPaidFor":6,"price":63900,"invoicePeriod":1},{"monthsPaidFor":7,"price":74550,"invoicePeriod":1},{"monthsPaidFor":8,"price":85200,"invoicePeriod":1},{"monthsPaidFor":9,"price":95850,"invoicePeriod":1},
{"monthsPaidFor":10,"price":106500,"invoicePeriod":1},{"monthsPaidFor":12,"price":117150,"invoicePeriod":12}],"code":"COMPLE36","name":"DStv Compact Plus","description":" "},{"availablePricingOptions":[{"monthsPaidFor":1,"price":15800,"invoicePeriod":1},
{"monthsPaidFor":2,"price":31600,"invoicePeriod":1},{"monthsPaidFor":3,"price":47400,"invoicePeriod":1},{"monthsPaidFor":4,"price":63200,"invoicePeriod":1},{"monthsPaidFor":5,"price":79000,"invoicePeriod":1},{"monthsPaidFor":6,"price":94800,"invoicePeriod":1},"code":"FTAE36","name":"DStv FTA Plus","description":" "}]}}
b). Find Product Add-ons for selected product
| Service | Find Product Add-ons |
|---|---|
| Request URL | baseUrl//api/v1/cabletv/multichoice/productaddons |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| serviceId | String | M | Multichoice service type – ‘dstv’ or ‘gotv’. |
Sample Request Body
{
"loginId": "1234",
"key": "f7a2b427d2…",
"serviceId": "dstv",
"primaryProductCode": "ACSSE36"
}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | statusDescription is a string that has embedded in it an ‘items’ object, which contains available products. items an array of composite objects – code, price, name, description |
Sample Response Body
{"statusCode":"00","statusDescription":{"items":[{"code":"ASIADDE36","price":5050,
"name":"Asian Add-on","description":" "},{"code":"HDPVRE36","price":2200,"name":"HDPVR\/XtraView","description":" "}]}}
3) VEND MULTICHOICE ACCOUNT
Now you can either RENEW an existing subscription or CHANGE PACKAGE to another
| Service | Vend Multichoice Account |
|---|---|
| Request URL | baseUrl/api/v1/cabletv/multichoice/vend |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
| serviceId | String | M | Multichoice service type – ‘dstv’ or ‘gotv’ |
| transactionRef | String | M | Unique transaction Id for the request. Maxlength (36characters) |
| customerNo | String | M | Customer number retrieved at validation stage. |
| customerName | String | M | Customer name retrieved at validation stage. |
| productsCodes | Array of strings | M | (For renew option leave as empty array [] ) An array of product/addon codes selected. Codes can be fetched from the related method calls (find standalone products and find product addons) |
| amount | Numeric | M | (For renew option amount is gotten from the validate customer API end point)Total transaction amount – in case of a 12 month invoice period, the product prices need to be multiplied by 11 |
| invoicePeriod | Numeric | M | Invoice period for which the payment is made. Retrieved when validating customer number. Can be either 1 or 12 (months) |
Sample Request Body Renew
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"serviceId": "gotv",
"customerNo": "300846162",
"customerName": "AYOBAMI OJO",
"productsCodes": [ ],
"amount": "800",
"invoicePeriod": "1",
"checksum": "{{checkSum}}",
"transactionRef": "te333u9u9j3949"
}
Sample Request Body Change Package
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"serviceId": "gotv",
"customerNo": "300846162",
"customerName": "CSW TEST",
"productsCodes": [ "GOHAN" ],
"amount": "800",
"invoicePeriod": "1",
"checksum": "{{checkSum}}",
"transactionRef": "tester23kfkej3u943"
}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | json | M | statusDescription is a json string that has embedded in it details of the transaction. If successful, it contains object such as amount, transactionNo (Creditswitch’s unique reference generated for the transaction) |
Sample Response Body Renew
{
"statusCode": "00",
"statusDescription": {
"message": "successful",
"amount": "4",
"type": "gotv",
"package": "Renewal",
"transactionRef": "test0bab9419g",
"transactionNo": "941851634826388"
}
}
Sample Response Body Change Package
{
"statusCode": "00",
"statusDescription": {
"message": "successful",
"amount": "4",
"type": "gotv",
"package": "GOtv Smallie - monthly",
"transactionRef": "test9j55216da",
"transactionNo": "280721634826502"
}
}
Betting Services
This service will help to fund a betting account across different betting providers.
1) FETCH PROVIDERS
| Service | This endpoint will return all the betting providers available |
|---|---|
| Request URL | {{baseUrl}}betting/providers?loginId={{loginId}}&key={{publicKey}} |
| HTTP Method | GET |
Request Parameters
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Successful",
"result": {
"B01T": "Bet9ja",
"B02T": "BangBet",
"B03T": "NairaBet",
"B04T": "SupaBet",
"B05T": "CloudBet",
"B06T": "BetLion",
"B07T": "1xBet",
"B08T": "MerryBet",
"B09T": "BetWay",
"B10T": "BetLand",
"B11T": "BetKing",
"B12T": "LiveScoreBet",
"B13T": "NaijaBet"
}
}
1) BET ACCOUNT VALIDATION
| Service | Betting Account validate |
|---|---|
| Request URL | {{baseUrl}}betting/validate |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| customerId | String | M | Id of Bet account |
| provider | String | M | name associated with fetch provider |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"customerId": "965820",
"provider" : "BetKing"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{"statusCode":"00","statusDescription":"Successful","result":{"status":"200","message":"Successful","name":"","username":"Arete995","type":"BetKing","customerId":"965820","reference":"163042564610000","accountNumber":null,"phoneNumber":null,"emailAddress":null,"canVend":null,"minPayableAmount":100,"charge":0},"status":true}
2) BET ACCOUNT FUNDING
| Service | Bet Account Funding |
|---|---|
| Request URL | {{baseUrl}}betting/pay |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| serviceId | String | M | B01T Is the service code for betting |
| customerId | String | M | Bet ID of the customer |
| fee | Numeric | M | Amount to fund Bet ID |
| Provider | string | M | Bet Provider associated with customer ID |
| name | string | M | name of the account associated with the Bet ID |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"serviceId" : "B01T",
"customerId":"34382",
"amount": 200,
"name" : "OLUFEMI ISAAC BABATUNDE",
"provider" : "BangBet"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{"statusCode": "00",
"statusDescription": "successful"
{
"status": true,
"result": {
"status": "200",
"message": "Transaction Successful",
"name": "Arete995",
"customerId": "965820",
"amount": "100.00",
"transId": "5624071398",
"date": "2021-08-24 12:23:34",
"type": "BetKing"
}
}
Toll Services
This service will fund a user's Toll Account.
1) TOLL ACCOUNT VALIDATION
| Service | Toll Account validate |
|---|---|
| Request URL | {{baseUrl}}toll/validate |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| customerId | String | M | Id of Toll account |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"customerId": "1234-00"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{"statusCode":"00","statusDescription":"Successful","result":{
"result": {
"status": "200",
"message": "Successful",
"type": "LCC",
"name": "TEST LCC_TESTER",
"customerId": "1234-00",
"reference": "162669082710000",
"accountNumber": null,
"phoneNumber": null,
"emailAddress": null,
"canVend": true,
"wallet": 2
}},"status":true}
2) TOLL ACCOUNT FUNDING
| Service | Toll Account Funding |
|---|---|
| Request URL | {{baseUrl}}toll/pay |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| serviceId | String | M | B01T Is the service code for betting |
| customerId | String | M | Bet ID of the customer |
| amount | Numeric | M | Amount to fund Bet ID |
| name | string | M | name of the account associated with the Bet ID |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"serviceId" : "B01T",
"customerId":"34382",
"amount": 200,
"name" : "OLUFEMI ISAAC BABATUNDE",
"provider" : "BangBet"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{"statusCode": "00",
"statusDescription": "successful"
{
"status": true,
"result": {
"status": "200",
"message": "Successfully processed the payment request",
"name": "OLUFEMI ISAAC BABATUNDE",
"customerId": "1234-00",
"amount": "100.00",
"transId": "0543869127",
"date": "2021-07-19 12:55:10",
"type": "LCC"
}
}
Re-Query Transaction
This is to retrieve detailed information or confirm the status of a previous transaction.
This service is useful for retrial implementation. Using the reference ID of an already initiated request, the final response of that
transaction can be called back – in order to determine whether a retry process should be triggered or not.
Note: The first requery should be done within a minimum of three (3) minutes after initiating the transaction.
| Service | Re-query Transaction |
|---|---|
| Request URL | baseUrl/api/v1/requery |
| HTTP Method | GET |
Request Parameters
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| requestId | String | M | Unique transaction Id for the request. Maxlength (36characters) |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
Sample Request Body
BASE_URL?loginId=17777&key=Ttdedbdc482f277243b&requestId=10B2E6F123&serviceId=A01E
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| MReference | Numeric | M | Unique transaction id supplied by the integrator for the request |
| tranxReference | Numeric | M | Merchant/client’s initial transaction reference |
| recepient | Numeric | M | Customers phone number to top-up |
| amount | Numeric | M | Amount with which to top-up amount customers phone Maximum 100000 |
| network | String | M | the actual network fulfilled by the telco |
Sample Response Body
{ "statusCode": "00","statusDescription": "Successful","tranxReference": 2052544278,"recipient": "08069314541",
"amount": "50.00","network": "MTN","mReference": "06773950c8ab","transactionDate": "2018-11-26 22:17:18"}
Logical PINS
This service will purchase a logical pin for the service ID provided. NOTE : Payload may differ depending on service ID. Logical Pin services cover the following AIRTEL,GLO,9MOBILE,MTN,JAMB,NECO,WAEC,NABTECH,SPECTRANET The respective service ID's can be found in the service ID table below.
1) FETCH PINS
| Service | Fetch All Pins |
|---|---|
| Request URL | {{baseUrl}}get_avail_pin_packages |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| serviceId | String | M | Corresponding service id for the request type |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"serviceId": "PO4N"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "successful",
"pinDetail": {
"pinValues": [
{
"amount": 100
},
{
"amount": 200
},
{
"amount": 500
},
{
"amount": 1000
},
{
"amount": 1500
}
]
}
}
2) LOGICAL PIN VEND
| Service | Logical PINS |
|---|---|
| Request URL | baseUrl/api/v1/vend_pins |
| HTTP Method | POST |
| Request Headers | application/json |
Request Parameters
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| recipient | Numeric | M | Phone number of the merchant |
| requestId | Numeric | M | Merchants unique id/reference for the transaction |
| amount | Numeric | M | Face Value of the PIN |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId":"38457","key":"***","checksum":"******","serviceId":"P01N",
"recipient":"080", "amount":"100","requestId":"4792sccfkdkfd8fdbxxclxcxg"}
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| tranxReference | String | M | Creditswitch transaction reference |
| qty | String | M | Quantity of PINs generated (usually 1) |
| amount | String | M | The face value of the generated pin |
| network | String | M | The actual network of the PIN |
| detail | String | M | Contains array of pin and serial number generated by the network operator |
Sample Response Body
{"statusCode": "00","statusDescription": "successful","detail": {"pin": ["614821599037390"],
"serialNo": ["903736148215990"],"network": "Airtel","qty": 1,"amount": "100","tranxReference": "354391599124667"}}
3) Validate Jamb
| Service | Validate Jamb Confirm Code |
|---|---|
| Request URL | {{baseUrl}}verify_jamb_candidate |
| HTTP Method | GET |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| Confirm Code | String | M | Individual Student Code gotten from Jamb Board |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"ConfirmCode": "a8h793b4f35f"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Successful",
"result": {
"gsmNo": "08000000000",
"lastName": "Amunike",
"firstName": "Emmanuel",
"middleName": "Michael"
}
}
5) Vend Jamb
| Service | Vend Jamb |
|---|---|
| Request URL | {{baseUrl}}vend_pins |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| Confirm Code | String | M | Individual Student Code gotten from Jamb Board |
| RequestId | String | M | Merchants unique id/reference for the transaction |
| ServiceId | String | M | Merchants id provided during integration |
| Amount | String | M | Face Value of the pin |
| Recipients | String | M | Phone number of the merchant |
| Checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
| String | M | Email of the candidate | |
| productType | String | M | Type of Jamb service |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"requestId": "{{requestId}}",
"serviceId": "P07N",
"amount": 4,
"recipient": "08012345678",
"checksum": "{{checkSum}}",
"email": "xyz@gmail.com",
"confirmCode": "1375779512",
"productType": "jambutme"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "successful",
"detail": {
"pin": "30138820169806991",
"serial_no": "094089700 1698060076",
"network": "JAMB",
"qty": 1,
"amount": 4,
"tranxReference": "2310231221161190695"
}
}
4) Vend Other Educational Services
| Service | Vend Other Educational Services |
|---|---|
| Request URL | {{baseUrl}}vend_pins |
| HTTP Method | POST |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| key | String | M | Merchants (public) key |
| RequestId | String | M | Merchants unique id/reference for the transaction |
| ServiceId | String | M | Merchants id provided during integration |
| Amount | String | M | Face Value of the pin |
| Recipients | String | M | Phone number of the merchant |
| Checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
| productType | String | M | Type of Jamb service |
Sample Request Body
{
"loginId": "{{loginId}}",
"key": "{{publicKey}}",
"requestId": "{{requestId}}",
"serviceId": "P06N",
"amount": 4,
"recipient": "08012345678",
"checksum": "{{checkSum}}",
"productType": "WAEC Checker"
}
NOTE: ‘statusCode’ = ‘00’ in response body implies success. If otherwise, it implies failed
Sample Response Body
{
"statusCode": "00",
"statusDescription": "successful",
"detail": {
"pin": "30138820169806991",
"serial_no": "094089700 1698060076",
"network": "WAEC",
"qty": 1,
"amount": 4,
"tranxReference": "2310231221161190695"
}
}
Electricity Validation Requests
Electricity top-up requests follow a somewhat different routine. And involves two steps.
Validation of the account/meter number to which top-up should be made is first made. Only after validation of the account/meter number is
Vending possible.
The validation logic, input parameters, and responses is somewhat similar for the all distribution companies,
however, responses to the vending request differs for different distribution companies.
Security checksum generation is covered in the Security: Checksum section
| Service | ELECTRICITY VALIDATION |
|---|---|
| Request URL | baseUrl/api/v1/evalidate |
| HTTP Method | POST |
| Request Headers | application/json |
Request Parameters
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| customerAccountId | Numeric | M | Customers unique identifier on distributors platform e.g Account Number or Meter Number |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId":1234,"serviceId":"E02E","customerAccountId":"0110347638",
"key":"0688378ec7fe233", checksum":"#2y*&23UnvC19" }
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| detail | Collection | M | An array of merchant customer’s detail |
"detail" Body:
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| name | String | M | Name of customer, as supplied by electric disco |
| address | String | M | Address to which the meter number belongs |
| accountId | String | M | Customer’s Account/Meter number |
| providerRef | String | M | Unique reference to identify transaction. To be supplied at the vending stage |
Sample Response Body
{"statusCode":"00","statusDescription":"successful",
"detail":{"name":"MR & MRS XD MICHAEL","address":"71 XAVIER CRESCENT ",
"accountId":"0110347638","providerRef":"150168371668"}}
Electricity Vending Requests
The request parameters to the vending endpoint remains the same across distribution companies.
Pay attention though to the Vending responses. Varying responses are returned for each electric disco.
Security checksum generation is covered in the Security: Checksum section
| Service | ELECTRICITY VENDING |
|---|---|
| Request URL | baseUrl/api/v1/evend |
| HTTP Method | POST |
| Request Headers | application/json |
Request Body:
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| customerAccountId | Numeric | M | Customers unique identifier on distributors platform e.g Account Number or Meter Number |
| amount | Numeric | M | Amount to top-up customers account/meter with |
| customerName | String | M | Name of Customer |
| requestId | Numeric | M | Merchants unique id/reference for the transaction |
| customerAddress | String | M | Address of the Customer |
| key | String | M | Merchants (public) key |
| checksum | String | M | Checksum computed for the request. See "Security: Checksum" section for hash computation steps |
Sample Request Body
{"loginId":"1234","key":"0688378ec7fe233",
"serviceId":"E02E","customerAccountId":"0110347638","requestId":1511693541,"amount":"1000","customerName": "MR & MRS. Test CSW",
"customerAddress": "93B, ODUDUWA CRESCENT, GRA, IKEJA, LAGOS","checksum": "$2y$10$rv89doOk0TdmGrWhyrj4gepYG6I3Toi5CSVdMV.mFmRvKBN\/\/JEE2"}
RESPONSES
PREPAID RESPONSE
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| detail | Collection | M | An array of merchant customer’s detail |
"detail" Body:
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| name | String | M | Name of customer, as supplied by electric disco |
| address | String | M | Address to which the meter number belongs |
| accountId | String | M | Customer’s Account/Meter number |
| amount | Numeric | M | Top-up amount |
| units | String | M | Units of power purchased |
| token | Numeric | M | Prepaid meter token generated on the disco’s end |
| tranxId | String | M | Unique Reference generated for the transaction |
Sample Response Body
{"statusCode":"00","statusDescription":"successful","detail":
{"name": "MR & MRS XD MICHAEL","address":"71 XAVIER CRESCENT ","accountId":"0110347638","amount":"1000",
"units":"788.14kWh","token":"01234567890123456789","tranxId":"20170727085357"}}
POSTPAID RESPONSES
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description for the status code. 00=Successful |
| detail | Collection | M | An array of merchant customer’s detail |
"detail" Body:
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| name | String | M | Name of customer, as supplied by electric disco |
| address | String | M | Address to which the meter number belongs |
| accountId | String | M | Customer’s Account/Meter number |
| amount | String | M | Top Up amount |
| tranxId | String | M | Unique Reference generated for the transaction |
Sample Response Body
{"statusCode":"00","statusDescription":"successful",
"detail":{"name":"MR & MRS XD MICHAEL","address":"71 XAVIER CRESCENT ",
"accountId":"0110347638","amount":"1000","tranxId":"150168371668"}}
Phone Number Look Up
Service to verify the network operator of an eleven digit Nigerian mobile number. This is a premium service.
| Service | PHONE NUMBER LOOKUP VALIDATION |
|---|---|
| Request URL | endpoint |
| HTTP Method | POST |
| Request Headers | application/json |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| msisdn | String | M | Eleven Digits Phone Number. Ex 09062120000 |
| key | String | M | Merchant (public) key |
Sample Request Body
{"loginId":1234,"msisdn":"09062120000","key":"0688378ec7fe233" }
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| statusCode | Numeric | M | Status of the transaction. 00 signifies success |
| statusDescription | String | M | Corresponding description of the status code. 00=Successful |
| network | String | M | Network operator of msisdn sent in request e.g MTN |
Sample Response Body
{"statusCode":"00","statusDescription":"successful","network":"MTN"}
Services
This section covers the services available to merchants, and the corresponding service codes for each service
| Service | Provider | Service Code |
|---|---|---|
| Airtime | ||
| Airtel | A01E | |
| 9 Mobile | A02E | |
| Globacom | A03E | |
| Mtn | A04E | |
| Data | ||
| Airtel | D01D | |
| 9 Mobile | D02D | |
| Globacom | D03D | |
| Mtn | D04D | |
| Smile | D05D | |
| NTEL | D06D | |
| LOGICAL PINS | ||
| Airtel | P01N | |
| 9 Mobile | P02N | |
| Globacom | P03N | |
| Mtn | P04N | |
| Spectranet | P05N | |
| WAEC | P06N | |
| JAMB | P07N | |
| NECO | P08N | |
| NABTECH | P09N | |
| Electricity | ||
| Ikeja Electric Disco (Prepaid Accounts) | E01E | |
| Ikeja Electric Disco (Post Accounts) | E02E | |
| Ibadan Electric Disco (Prepaid Accounts) | E03E | |
| Ibadan Electric Disco (Postpaid Accounts) | E04E | |
| Eko Electric Disco (Prepaid Accounts) | E05E | |
| Eko Electric Disco (Postpaid Accounts) | E06E | |
| Abuja Electric Disco (Prepaid Accounts) | E07E | |
| Abuja Electric Disco (Postpaid Accounts) | E08E | |
| Port Harcourt Electric Disco (Prepaid Accounts) | E09E | |
| Port Harcourt Electric Disco (Postpaid Accounts) | E10E | |
| Kaduna Electric Disco (Prepaid Accounts) | E11E | |
| Kaduna Electric Disco (Postpaid Accounts) | E12E | |
| Jos Electric Disco (Prepaid Accounts) | E13E | |
| Jos Electric Disco (Postpaid Accounts) | E14E | |
| Enugu Electric Disco (Prepaid Accounts) | E15E | |
| Enugu Electric Disco (Postpaid Accounts) | E16E | |
| Kano Electric Disco (Prepaid Accounts) | E17E | |
| Kano Electric Disco (Postpaid Accounts) | E18E | |
| Insurance | ||
| INSURANCE | INS0 | |
| SHOWMAX | ||
| SHOWMAX | S0MX |
Security: Checksum
The Creditswitch REST API uses an authentication scheme which utilizes the Bcrypt hashing algorithm.
Each merchant has a private and public key. To authenticate a request, you first concatenate certain selected elements of the request
(including the merchant’s private key) to form a string.
Next you generate the hash of the concatenated string in the previous step
using the Bcrypt algorithm. Finally, get the base-64 encoding of the hash. When the system receives an authenticated request,
it fetches the Creditswitch’s secret access key you claim to have, and uses it in computing the checksum in the same way you should have.
If the two checksums match, the system concludes the requester must have access to the secret key,
and therefore acts with the authority of the integrator to whom the key was issued.
If there is a mismatch, the request is dropped, and the system responds with an error message.
The following illustrates the construction of the requests’ checksum. The output of the Bcrypt hash is a string.
Airtime/Data Request
ConcatString = loginId + "|" + requestId + "|" + serviceId + "|" + requestAmount + "|" + privateKey + "|" + recipient;
Checksum = Base64(Bcyrpt(ConcatString));
Electric Validate Request
ConcatString = loginId + "|" + serviceId + "|" + privateKey + "|" + customerAccountId;
Checksum = Base64(Bcyrpt(ConcatString));
Electric Vend Request
ConcatString = loginId + "|" + serviceId + "|" + privateKey + "|" + customerAccountId + "|" + requestId + "|" + amount;
Checksum = Base64(Bcyrpt(ConcatString));
Merchant Details Request
ConcatString = loginId + "|" + privateKey;
Checksum = Base64(Bcyrpt(ConcatString));
Deduct Mobile Subscriber's Airtime Request
loginId + "|" + privateKey + "|" + msisdn+ "|" + amount;
Checksum = Base64(Bcyrpt(ConcatString));
Send SMS
ConcatString = loginId + "|" + privateKey + "|" + transactionRef;
Checksum = Base64(Bcyrpt(ConcatString));
Cable TV: Startimes Validate
ConcatString = loginId + "|" + privateKey + "|" + smartCardCode;
Checksum = Base64(Bcyrpt(ConcatString));
Cable TV: Startimes Vend
ConcatString = loginId + "|" + privateKey + "|" + smartCardCode + "|" + fee;
Checksum = Base64(Bcyrpt(ConcatString));
Cable TV: Validate Multichoice SmartCard/Customer Number
ConcatString = loginId + "|" + privateKey + "|" + customerNo;
Checksum = Base64(Bcyrpt(ConcatString));
Cable TV: Vend Multichoice Account
ConcatString = loginId + "|" + privateKey + "|" + customerNo + "|" + transactionRef + "|" + amount;
Checksum = Base64(Bcyrpt(ConcatString));
Logical Pins: Vend logical Pins
ConcatString = loginId + "|" + serviceId + "|" + privateKey + "|" + requestId + "|" + amount;
Checksum = Base64(Bcyrpt(ConcatString));
Security: Checksum Generation Snippets
Sample checksum generation snippets in some selected languages. These snippets are only meant to serve as a guide.
PHP
public function getChecksumAirtimeData(){
$loginId = "1234";
$requestId = "112345";
$serviceId = "A04E";
$requestAmount = "100";
$privateKey = "78858c42aff6b2210a2fdc637f6ebe39d53c38da95633d27f52fddeace60149162";
$recipient = "08030001111";
$concatString = $loginId ."|". $requestId."|". $serviceId."|".$requestAmount."|".$privateKey."|". $recipient;
$checksum = base64_encode(password_hash($concatString, PASSWORD_DEFAULT) ); //PASSWORD_BCRYPT
return $checksum;
}
public function getChecksumMertDetail(){
$loginId = "1234";
$privateKey = "78858c42aff6b2210a2fdc637f6ebe39d53c38da95633d27f52fddeace60149162";
$concatString = $loginId ."|".$privateKey;
$checksum = base64_encode(password_hash($concatString, PASSWORD_DEFAULT) ); //PASSWORD_BCRYPT
return $checksum;
}
Python
import bcrypt
def getChecksumAirtimeData():
loginId = "1234"
requestId = "112345"
serviceId = "A04E"
requestAmount = "100"
privateKey = "78858c42aff6b2210a2fdc637f6ebe39d53c38da95633d27f52fddeace60149162"
recipient = "08030001111"
concatString = loginId +"|"+requestId+"|"+serviceId+"|"+requestAmount+"|"+privateKey+"|"+recipient;
checksum = base64.urlsafe_b64encode(bcrypt.hashpw(concatString, bcrypt.gensalt()))
return checksum
def getChecksumMertDetail():
loginId = "1234"
privateKey = "78858c42aff6b2210a2fdc637f6ebe39d53c38da95633d27f52fddeace60149162"
concatString = loginId+"|"+privateKey
checksum = base64.urlsafe_b64encode(bcrypt.hashpw(concatString, bcrypt.gensalt()))
return checksum Java
static String getChecksumAirtimeData(){
String loginId = "1234";
String requestId = "112345";
String serviceId = "A04E";
int requestAmount = 100;
String privateKey = "78858c42aff6b2210a2fdc637f6ebe39d53c38da95633d27f52fddeace60149162";
String recipient = "08030001111";
String concatString = ""+loginId +"|"+requestId+"|"+serviceId+"|"+requestAmount+"|"+privateKey+"|"+recipient+"";
byte[] message = Bcrypt.hashpw(concatString,Bcrypt.gensalt()).getBytes(StandardCharsets.UTF_8);
String checksum = Base64.getEncoder().encodeToString(message);
String checksum = Base64.getEncoder().encodeToString(message);
return checksum;
}
static String getChecksumMertDetail(){
String loginId = "1234";
String privateKey = "78858c42aff6b2210a2fdc637f6ebe39d53c38da95633d27f52fddeace60149162";
String concatString = ""+loginId+"|"+privateKey;
byte[] message = Bcrypt.hashpw(concatString,Bcrypt.gensalt()).getBytes(StandardCharsets.UTF_8);
String checksum = Base64.getEncoder().encodeToString(message);
return checksum;
}
.NET C#
public string getCheckSum() {
string loginId = "1234";
string requestId = "bchsbhhbfdsbsdbh";
string serviceId = "A04E";
string amount = "100";
string privatekey = "XY1t9Y159hWJaETD";
string recipient = "07027829028";
var concatText = loginId + "|" + requestId + "|" + serviceId + "|" + amount + "|" + privatekey + "|" + recipient;
string salt = BCryptHelper.GenerateSalt();
var hashedText = BCryptHelper.HashPassword(concatText, salt);
return checkSum = Convert.ToBase64String(Encoding.UTF8.GetBytes(hashedText));
} Error Codes and Description
| RESPONSE CODES | DESCRIPTION |
|---|---|
| 00 | Successful |
| C001 | Processing |
| V001 | Bad Request |
| V0101 | Generic Validation Error |
| V002 | Checksum Mismatch |
| V003 | Unrecognized service code |
| V004 | User access blocked |
| V005 | User account is inactive |
| V010 | Discount not configured for merchant |
| V011 | Airtime vend method call exception |
| V015 | User’s balance couldn’t be retrieved |
| V016 | Not enough funds to satisfy request |
| V020 | Provider Login not configured for merchant |
| EXC001 | Duplicate merchant transaction reference supplied |
| EXC002 | Unknown exception or Service Unavailable |
| EXC022 | Connection Error |
| PROG001 | Programming Error |
| C01 | User Limit Exceeded |
| C0101 | Response Parse Error |
| C02 | Provider Duplicate Transaction Id |
| C03 | Batch Inactive/Provider Not Responding |
| C04 | Response Timeout |
| C11 | Fraud Limit on Multiple Recharges within 90 seconds |
| C12 | Provider Side Invalid Subscriber Number |
| C13 | Provider Side Platform Error |
| C20 | User Account Error , Connection Error |
| C21 | Vendor Side Authentication Error |
| C100 | Other Errors |
Response code C001 indicates that the transaction is processing, and it should be taken as successful because such transaction will be fulfilled later, in an event of service disruption at the Mobile Network Operators.
USSD SOLUTIONS
Overview
This document gives a description of the USSD web service exposed on the
Creditswitch Platform which enables business partners’ display their USSD menu.
For technical assistance with the CSW API contact us at techsupport@creditswitch.com to enable swift response and support.
Integration
This section contains a description of recommended integration flow which helps minimize the risk of disputing transactions and also increase customer confidence in the system
For a secure transfer of data between Creditswitch server and client’s server, a secured connection is required. This can be achieved via a VPN a connection, https or other secured protocols.
External USSD Application Service
This service allows a client to be able to display their preferred menu via USSD. Creditswitch will append user’s request parameters and push to the provided endpoint. A JSON response is expected for this request.
| Service | Merchant Info |
|---|---|
| Request URL | To be provided by the client |
| HTTP Method | GET |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| msisdn | Numeric | M | Customer’s 13 digit phone number e.g. 2347055699312 |
| input | String | M | For first dial, this fields comes with the short (without #) e.g *444 subsequently, with the user’s input e.g. 1 |
| sessionid | String | M | This displays a unique numeric ID for each request |
| network | String | M | It identifies the network providers’ which includes MTN, Glo, Airtel or 9Mobile |
| action | String | M | This could either be begin, request, or end begin– means a new request request – means session should be continued end – means session should be ended |
| allinput | String | M | For first dial, this fields comes with the short (without #) e.g .*444 subsequently, the concatenation of the initial input and other user input e.g.*444*1 |
Sample Request Body
http://CLIENT_FULL_BASEURL?msisdn=23478599658965&input=*444&sessionid=123555522&net work=MTN&action=begin&allinput=*444*1
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| message | String | M | String of message (140 characters) to be displayed to the user |
| action | String | M | This could either be request or end request – means session should be continued end – means session should be ended |
Sample Response Body
{"message": "Welcome to Creditswitch\n\n1.Airtime/Data\n2.Airtime Swap\n3.Fund Wallet\n4.Balance\n5.Transactions\n6.Change PIN", "action":"request" }
USSD Push Notification Application Service
This API describe how a third party can initiate USSD push to subscriber mobile phone number from CreditSwitch Platform.
| Service | Merchant Info |
|---|---|
| Request URL | http://BASEURL:PORT |
| HTTP Method | GET |
Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| msisdn | Numeric | M | 13 digit Phone number of the subscriber that will receive the push |
| network | String | M | Mobile network of the subscriber |
| username | String | M | The username that was assigned to the third-party user during integration |
| password | String | M | The Password that was assigned to the third-party user during integration |
| msg | String | M | A 130-character text that will be display to subscribers |
| msg_type | String | M | This could either be begin, continue, or end begin– means apass as instruction to create new session. continue-will allow subscriber response back. End – means terminate the sessiong |
| sessionid | String | O | set this to empty string when msg_type is begin, for continue and end request you should return back the generated sessionid |
Sample Request Body
"http://BASEURL:PORT/ussd_push?msg= welcome to Creditswitch
Pro\n\n1.Win 10,000 airtime\n2.Refer a friend&msisdn=23480000000&username=xyz&password=xzy&msg_type=continue&network=MTN&sessionid=111192029228292"
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| msisdn | String | M | msisdn provided in the payload |
| sessionid | String | M | Session Id for the request |
| network | String | M | Network of the msisdn provided |
| input | String | M | user input (it could be empty if it does not require input from the user) |
Sample Response Body
{"msisdn":" 23480000000","sessionid":"111192029228292","network":"MTN","input":"1"}
UTILITY ADVANCE SERVICE
Overview
This document gives an overview of the Creditswitch Utility Advance service. This service enables business partners to consume existing services on the Creditswitch Platform in a buy now pay later fashion.
For technical assistance with the CSW API contact us at techsupport@creditswitch.com to enable swift response and support.
Integration Process Flow
This section contains a description of recommended integration flow which helps minimize the risk of disputing transactions and also increase customer confidence in the system
1) Authentication: Begin by authenticating through the Login Endpoint to retrieve a bearer token for subsequent API calls.
2) Loan Eligibility Check: Call the Loan Eligibility Endpoint with the specified payload. This step confirms eligibility and returns potential loan offers if eligible.
3) Loan Approval: If the user accepts the terms and conditions presented in step 2, the system automatically processes the loan disbursement/approval.
4) Loan Status: Check the status of an existing loan, utilize the status endpoint.
5) Loan Repayment: To close an existing loan, utilize the Repayment Endpoint as needed.
1) Authentication
Generate bearer token for subsequent API calls.
| Service | Login - Generate Auth Token |
|---|---|
| Request URL | baseUrl/api/v1/login |
| HTTP Method | POST |
| Request Headers | Content-Type: application/json X-Signature: {{encrypted_checksum}} |
Sample Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| M | Configured Email Address | ||
| password | String | M | Password |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. true signifies success |
| code | Integer | M | Corresponding description for the status. 200 = Successful |
| message | String | M | Description of the api response. |
| data | Object | M | An object containing authentication details. |
Sample Response Body
{
"status":true,
"code":200,
"message":"Successful",
"data": {
"token_type": "Bearer",
"access_token": "eyJygurwiyugiwbreugijbiwqhfiywefgibwa",
"expires_at": 7200,
"name": "John Doe",
"email": "john.doe@example.com"
}
}2) Loan Eligibility Check
This action confirms recipient's eligibility using agreed metrics and returns with loan offers where eligible.
Client is required to make a POST request to this endpoint.
| Service | Loan Eligibility Check |
|---|---|
| Request URL | baseUrl/api/v1/loan/eligibility/check |
| HTTP Method | POST |
| Request Headers | Content-Type: application/json Bearer: {{access_token}} X-Signature: {{encrypted_checksum}} |
Sample Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | String | M | Merchant Id provided during integration |
| serviceType | String | M | airtime or data |
| recipient | Numeric | M | Customers phone number |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. true signifies success |
| code | Integer | M | Corresponding description for the status. 200 = Successful |
| message | String | M | Description of the api response. |
| data | Object | M | An object containing check response with available offer(s). |
Sample Response Body
{
"status": true,
"code": 200,
"message": "Successful",
"data": {
"offer1": {
"amount": "200",
"serviceId": "A04E",
"product": "airtime"
},
"offer2": {
"amount": "100",
"serviceId": "A04E",
"product": "airtime"
},
"isEligible": true,
"reference": "077416241021064788727052243034"
},
"meta": null
}3) Disburse Loan
This action confirms recipient's consent to the loan terms and conditions as indicated by the response returned from step 2) above.
Client is required to make a POST request to this endpoint.
| Service | Disburse Loan |
|---|---|
| Request URL | baseUrl/api/v1/loan/apply |
| HTTP Method | POST |
| Request Headers | Content-Type: application/json Bearer: {{access_token}} X-Signature: {{encrypted_checksum}} |
Sample Request Body (Airtime)
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| loginId | Numeric | M | Merchant id provided during integration |
| requestId | String | M | Unique transaction Id for the request. Maxlength (36characters) |
| serviceId | String | M | Corresponding service id for the request type. See "Services" section for the available services and corresponding service codes for each. |
| amount | Numeric | M | Amount with which to top-up amount customers phone Maximum 100000 |
| recipient | Numeric | M | Customers phone number to top-up |
Sample Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. true signifies success |
| code | Integer | M | Corresponding description for the status. 200 = Successful, 202 = Processing, 422 = Failed |
| message | String | M | Description of the vend response. |
| data | Object | M | An object containing vend response details. |
Sample Responses
{
"status": true,
"code": 200,
"message": "Loan Advance Approved Successfully",
"data": {
"requestId": "jc1bciigdebc",
"recipient": "08092343261",
"amount": "90.00",
"confirmCode": "1705997694210722624497994",
"network": "9Mobile",
"tranxDate": "23-01-2024 9:14 am",
"serviceCharge": "10.00"
},
"meta": null
}
{
"status": true,
"code": 202,
"message": "Your transaction is being processed... Kindly run TSQ in 5 minutes",
}
{
"status": false,
"code": 422,
"message": "Failed to fulfil request",
}
4) Get Loan Status
This endpoint is used to confirm the status of a loan application.
| Service | Retrieve Utility Loan Status |
|---|---|
| Request URL | baseUrl/api/v1/loan/status/{requestId} |
| HTTP Method | GET |
| Request Headers | Content-Type: application/json Bearer: {{access_token}} X-Signature: {{encrypted_checksum}} |
Sample Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. true signifies success |
| code | Integer | M | Corresponding description for the status. 200 = Successful |
| message | String | M | Description of the status check response. |
| data | Object | M | An object containing utility loan details. |
Sample Response Body
{
"status": true,
"code": 200,
"message": "Loan Request Retrieved Successfully",
"data": {
"requestId": "9a1d44fij437",
"recipient": "07067729339",
"amount": 100,
"confirmCode": "2021063019080126701629681",
"network": "MTN",
"tranxDate": "17-01-2024 2:06 pm",
"serviceCharge": "10.00",
"status": "Open"
},
"meta": null
}5) Repay Utility Loan
This endpoint is used to finalized or close out an outstanding loan. To confirm the outstanding payment, a call the the loan status endpoint will suffice
| Service | Repay Utility Loan |
|---|---|
| Request URL | baseUrl/api/v1/loan/repay |
| HTTP Method | POST |
| Request Headers | Content-Type: application/json Bearer: {{access_token}} X-Signature: {{encrypted_checksum}} |
Sample Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| requestId | String | M | Unique transaction Id for the request. Maxlength (36characters) |
| amount | Numeric | M | Outstanding Loan Amount. Note: It must be the exact amount as indicated by get loan status. |
Sample Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. true signifies success |
| code | Integer | M | Corresponding description for the status. 200 = Successful |
| message | String | M | Description of the status repayment request. |
| data | Object | M | An object containing utility loan repayment details. |
Sample Response Body
{
"status": true,
"code": 200,
"message": "Loan status updated successfully",
"data": {
"message": "Loan status updated successfully"
},
"meta": null
}LOW BALANCE SERVICE (AUTO TOP-UP)
Overview
This document gives an overview of the Creditswitch low balance service. This is a subscription based service that enables customer to top up their balance while making calls .
For technical assistance with the CSW API contact us at techsupport@creditswitch.com to enable swift response and support.
Integration Process Flow
This section contains a description of recommended integration flow which helps minimize the risk of disputing transactions and also increase customer confidence in the system
1) Onboarding: Begin by authenticating through the onboard Endpoint to retrieve a token for subsequent API calls.
2) Subscription: Call the Auto Top up subscription Endpoint with the specified payload. This step allows user to subscribe to the service.
3) Unsubscribe: If the customer wishes to unsubscribe from the Low Balance service, Call the unsubscribe endpoint to cancel active subscription.
1) Onboarding
Generate token for subsequent API calls.
| Service | Onboard - Generate Auth Token |
|---|---|
| Request URL | baseUrl/api/v1/low/balance/create/vendor |
| HTTP Method | POST |
| Request Headers | Content-Type: application/json |
Sample Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| Merchant Login Id | String | M | Merchant LoginId |
| Merchant Name | String | M | Merchant Name |
| Call-back URL | String | M | Merchant Callback Url |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. |
| statusDescription | String | M | Corresponding description for the status. |
| data | Object | M | An object containing authentication details. |
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Account created successfully",
"data": "srUNEuasfbs_UtcuwJHIVWO-euJHCHVcggfw"
}2) Subscription
Call the Auto Top up subscription Endpoint with the specified payload. This step allows user to subscribe to the service.
Client is required to make a POST request to this endpoint.
| Service | Subscription |
|---|---|
| Request URL | baseUrl/api/v1/low/balance/subscribe |
| HTTP Method | POST |
| Request Headers | Content-Type: application/json |
Sample Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| msisdn | String | M | Customers Msisdn |
| amount | String | M | amount to top up |
| threshold | String | M | threshold at which service should trigger |
| Threshold Type | String | M | trigger type weather for airtime or data |
| network | String | M | customers msisdn network provider |
| createdAt | String | O | request timestamp |
Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. |
| statusDescription | String | M | Corresponding description for the status. |
| data | String | O | response data if any. |
Sample Response Body "statusCode": "string", "statusDescription": "string", "data": "string"
{
"statusCode": "00",
"statusDescription": "Subscription is successful",
"data": "udgsigiub_bjadvb"
}
3) Unsubscribe
If the customer wishes to unsubscribe from the Low Balance service, Call the unsubscribe endpoint to cancel active subscription.
Client is required to make a DELETE request to this endpoint.
| Service | Unsubscribe |
|---|---|
| Request URL | baseUrl/api/v1/low/balance/{{msisdn}}/{{thresholdType}}/unsubscrible |
| HTTP Method | DELETE |
| Request Headers | Content-Type: application/json |
Sample Request Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| msisdn | String | M | Customers Msisdn |
| Threshold Type | String | M | trigger type weather for airtime or data |
Sample Response Body
| Parameter Name | Type | M/O | Description |
|---|---|---|---|
| status | String | M | Status of the request. |
| statusDescription | String | M | Status Description of the request. |
Sample Response Body
{
"statusCode": "00",
"statusDescription": "Unsubscribed"
}
4) Notifications Callback
A Low balance notification is trigger to you if the subscriber airtime/data balance is below their threshold and a successful response will also trigger value to be given to the subscriber.
Callback Event -- notification request
{"subscriberMSISDN": "0803xxxxxxx", "airtimeThreshold": "50", "network": "MTN", "dataThreshold": "", "thresholdType": "airtime", "transactionId": "251068796011729491882", "event": "notification"}
Callback Event -- notification Expected Response
{"status":true,"code":200,"message":"Debited Successful","data":{"isDebited":true,"transaction_reference":"931ATT6715e690775841729488528","amount":"100","recipient":"0803xxxxxxxxxxxx"}}
Callback Event -- update request
{"statusCode": "00", "statusDescription": "Successful", "confirmCode": "251068796011729491882", "tranxReference": "931ATT6715e690775841729488528", "event": "update"}
Callback Event -- update Expected Response
{
"status":true,
"code":200,
"message":"update Successful"
}
